CMA Dishmachines GL-X Owner's Manual
Installation & operation
Hide thumbs
Also See for GL-X:
- Owner's manual (19 pages) ,
- Parts manual (18 pages) ,
- Quick setup instructions (2 pages)
Related Manuals for CMA Dishmachines GL-X
Summary of Contents for CMA Dishmachines GL-X
- Page 1 Owner’s Manual MODEL GL-X INSTALLATION & OPERATION Rev. 1.01B C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E...
-
Page 2: Table Of Contents
ABLE OF ONTENTS CMA-GL-X ODEL 1. SPECIFICATIONS ..................2 1.1. GL-X .............................. 2 1.2. GLX O ......................3 PERATIONAL YCLE 2. GETTING STARTED ..................5 2.1. GL-X ......................5 NTRODUCTION TO THE 2.2....................... 6 ECEIVING AND NSTALLATION 2.2.1. Electrical ..........................6 2.2.2. -
Page 3: Specifications
13.4 AMPS *MUST CONNECT TO DEDICATED SUPPLY CIRCUIT. COMPLIANCE WITH LOCAL ELECTRICAL CODES MUST BE FOLLOWED. SHIPPING WEIGHT GL-X (Approximate) 244# 110.6 kg Note: The required flowing water pressure to the dishwasher is 15-65 PSIG. If pressures higher than 65 PSIG are present, a pressure regulating valve must be installed in the water line to the dishwasher (by others). -
Page 4: Glx Operational Cycle
After about 2 seconds, Cam 1—the Start cam—latches ON the power to the cam timer motor and drops out the instant start relay. The cam timer motor continues MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE... - Page 5 7. Cam switch 8 operates the optional sustainer heater. This cam assures that the sustainer heater only turns on when the dishmachine is not in a cycle. This prevents the machine from drawing too much electrical current at any one time. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE...
-
Page 6: Getting Started
130°F and 140°F when machine is not in operation. The supply water to the GL-X must be a minimum of 140°F. The pipe supplying the water must be ½” minimum. The plumbing connection is located at the back of the machine. The drain is a 1"... -
Page 7: Receiving And Installation
Prior to installation make sure the electrical supply is compatible with the specifications on the machines data plate. 115 volt, 60 Hz dedicated circuit must be used to supply electrical power to the GL-X machine (see specification sheet page 2). -
Page 8: Plumbing
Federal, State, and Local Health, Electrical, Plumbing and Safety codes The de-liming agents used to de-scale a commercial dishwasher, are highly caustic and de-liming must be done by a qualified chemical specialist. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE... -
Page 9: Operation
instructions. The chemicals and water level must be programmed by a qualified chemical specialist. The de-liming agents are highly caustic and de-liming must be done by qualified chemical specialist. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE... -
Page 10: Pre-Scrapping
It is essential that the operator thoroughly understand the importance of pre-scrapping the glasses before loading them. The GL-X is equipped with a removable drain screen. The drain screen can be easily removed for cleaning between Operational Cycles of the dishmachine. -
Page 11: Maintenance
Maintenance 4. Maintenance The maintenance procedures detailed in this section are to be performed by qualified personnel. 4.1. Timer assembly The standard timer assembly consists of a (2 minutes per revolution) motor turning a common shaft, which, in turn, rotates eight cams. As the cams rotate, they control various functions and the sequence of the operational cycle. -
Page 12: Quick Service Guide
Replace solenoid coil, P/N 00738.10 NORMAL Delimer switch in wrong position Switch to position Sanitizer pump does not run Faulty 5th micro switch Replace switch, P/N 00411.00 Faulty sanitizer pump motor Replace motor, P/N 00416.00 MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE... -
Page 13: Troubleshooting
Replace heater relay P/N: 00631.00 *The timer assembly motor ( ) or micro switches ( ) can be replaced P/N: 00501.00 P/N: 00411.00 independently if that is the only component that has failed. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE... - Page 14 P/N: 00408.80 (Cam 5) *The timer assembly motor ( ) or micro switches ( ) can be replaced P/N: 00501.00 P/N: 00411.00 independently if that is the only component that has failed. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE...
- Page 15 Replace pump motor P/N: 00201.00 *The timer assembly motor ( ) or micro switches ( ) can be replaced P/N: 00501.00 P/N: 00411.00 independently if that is the only component that has failed. MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE...
-
Page 16: Addendum For Machines Installed In The City Of Chicago
Addendum 5. Addendum for Machines Installed in the City of Chicago “All food dispensing establishments using chlorine or other approved chemical sanitizers shall, at all times, maintain an adequate testing device.” “Dishes and other eating and drinking utensils to be washed in a dishwashing machine shall be properly scraped and pre-rinsed and shall be stacked in racks or trays so as to avoid overcrowding, and so as to permit the wash and rinse waters to reach all surfaces of each utensil.”... -
Page 17: Appendix A: Operator & Cleaning Instructions
Appendix A: Operator & Cleaning Instructions Page MODEL GLX INSTALLATION & OPERATION MANUAL Rev. 1.01B... -
Page 18: Electrical Diagram
Electrical Diagram 6. Electrical Diagram Page MODEL GLX INSTALLATION & OPERATION MANUAL Rev. 1.01B... - Page 19 Electrical Diagram MODEL GL-X INSTALLATION & OPERATION MANUAL Rev. 1.01B PAGE...
