Industrial Stations EE 8000
Button module EM 605
Button module with 6 LED direct dialling buttons. The buttons can be programmed with various
functions. For labelling of the buttons exchangeable tags are included.
Industrial push buttons with micro-switch.
Microphone module EM 660
Microphone module with universal microphone and 2 buttons. The DSP provides the possibility, to
have a single microphone working for omnidirectional and noise-cancelling characteristics. The two
buttons can be programmed with various functions.
Button labels "L" and "X" are included in extent of supply.
Microphone module EM 680
Microphone module with universal microphone and 2 LED buttons. The DSP provides the possibility,
to have a single microphone working for omnidirectional and noise-cancelling characteristics. The two
buttons can be programmed with various functions.
Button labels "L" and "X" are included in extent of supply.
3.1/0614
Technical data:
Measurements: 140 x 100 x 50 mm (5.5 x 3.9 x 2 in)
Colour:
Module code: 5
Technical data:
Speaking distance:adjustable 3 cm–5 m (1.2 in–16.4 ft)
Microphone:
Microphone sensitivity:
Maximum ambient noise level:
Measurements: 140 x 100 x 85 mm (5.5 x 3.9 x 3.3 in)
Colour: orange (RAL 2004) / microphone black
Module code: 6
Technical data:
Speaking distance:adjustable 3 cm–5 m (1.2 in–16.4 ft)
Microphone:
Microphone sensitivity:
Maximum ambient noise level:
Measurements: 140 x 100 x 85 mm (5.5 x 3.9 x 3.3 in)
Colour: orange (RAL 2004) / microphone black
Module code: 8
Concept and Components
orange (RAL 2004)
Universal microphone
–21 dB to +12 dB
up to 95 dBA
Universal microphone
–21 dB to +12 dB
up to 95 dBA
