Commend EE 8000 Product Manual page 10

Concept and Components
Microphone module EM 681
Microphone module with universal microphone, 1 LED button and a big red mushroom button with
"SOS" print. The DSP provides the possibility, to have a single microphone working for omnidirectio-
nal and noise-cancelling characteristics. The two buttons can be programmed with various functions.
Button labels "L" and "X" are included in extent of supply.
Microphone module EM 6B0
Microphone module with universal microphone, white conversation lamp and a big red mushroom
button with "SOS" print. The DSP provides the possibility, to have a single microphone working for
omnidirectional and noise-cancelling characteristics. The button can be programmed with various
functions.
Dummy module EM 600
Dummy module to fill empty module slots or for fitting of customer specific buttons etc.
Dummy module EM 6A0
Dummy module with "SOS" print to fill empty module slots
10
Technical data:
Speaking distance:adjustable 3 cm–5 m (1.2 in–16.4 ft)
Microphone:
Microphone sensitivity:
Maximum ambient noise level:
Measurements: 140 x 100 x 85 mm (5.5 x 3.9 x 3.3 in)
Colour: orange (RAL 2004) / microphone black
Module code: D
Technical data:
Speaking distance:adjustable 3 cm–5 m (1.2 in–16.4 ft)
Microphone:
Microphone sensitivity: adjustable –21 dB to +12 dB
Maximum ambient noise level:
Measurements: 140 x 100 x 85 mm (5.5 x 3.9 x 3.3 in)
Colour: orange (RAL 2004) / microphone black
Module code: B
Technical data:
Measurements: 140 x 100 x 37 mm (5.5 x 3.9 x 1.5 in)
Colour:
Module code: 0
Technical data:
Measurements: 140 x 100 x 37 mm (5.5 x 3.9 x 1.5 in)
Colour:
Module code: A
Industrial Stations EE 8000
Universal microphone
–21 dB to +12 dB
up to 95 dBA
Universal microphone
up to 95 dBA
orange (RAL 2004)
orange (RAL 2004)
3.1/0614
