Kit Overview

The SAM R34 Xplained Pro Evaluation Kit is a hardware platform used to evaluate the ATSAMR34 Low
Power LoRa
The kit offers a set of features that enable the user to get started with the ATSAMR34 Low Power LoRa
Sub-GHz SiP peripherals right away, and to understand how to integrate the device in their own design.
The SAM R34 Xplained Pro Evaluation Kit contains the following items:
• One SAM R34 Xplained Pro Evaluation Board
• One external antenna
Battery
Power Source
J102
SMA
ATSAMR34J18B
©
