1.

Introduction

1.1

Features

• Kit Supports 868MHz and 915MHz Dual (Wideband) ISM Band
• On-Board Embedded Debugger (EDBG):
–
–
–
–
–
–
–
• Embedded Current Measurement Circuitry with
• Two Mechanical Buttons (User-Configurable Button and RESET Button)
• Two User LEDs (Soft Orange and Green)
• One QTouch
• USB Interface, Device and Reduced Host Mode
• Two Xplained Pro Extension Headers
• Antenna:
–
–
• Three Possible Power Sources:
–
–
–
• Clock Source:
–
–
• Supported with application examples in the Atmel Software Framework
1.2

Kit Overview

The SAM R30 device is an ARM-based, ultra low-power microcontroller (MCU) equipped with an IEEE
802.15.4-2003/2006/2011 standard that is compliant with RF interfaces for the sub-1GHz frequency
bands, such as 780 MHz (China), 868 MHz (Europe), and 915 MHz (North America). It uses the 32-bit
®
ARM Cortex
offers 256KB of Flash and 40KB of SRAM in both 32-pin and 48-pin packages.
The SAM R30 device supports the following power managaement techniques to reduce current
consumption:
• Power Gating
• SleepWalking
©
2017 Microchip Technology Inc.
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
Auto-ID for board identification in Studio
One status LED (yellow)
One power supply LED (green)
Symbolic debug of complex data types including scope information
Programming and debugging including power measurements
Data Gateway Interface: Serial Peripheral Interface (SPI) bus, Inter-Integrated Circuit (I
and four General Purpose Input/Outputs (GPIOs)
Virtual COM Port (CDC)
®
Button
One ceramic chip antenna (Johanson Technology – 0900AT43A0070)
One SMA connector for external antenna
External power
Embedded Debugger (EDBG) USB
TARGET USB
32.768 kHz crystal, a clock source for the controller in the SAM R30 device
16 MHz crystal for the RF die in the SAM R30 device
®
- M0+ processor, which operates at a maximum of 48 MHz (2.46 CoreMark
ATSAMR30-XPRO
Data Visualizer Support for Data Visualization
User Guide
2
C)
®
®
/MHz) and
DS50002612A-page 4
