Parts provided with the EXTender

Table 2: Part Provided with the EXTender
Quantity Description
1 EXTender 6000
1 Power Cord
1 DB-25, RS-530 cable
1 DB-9 RS-232 cable
1 Cat 5 Ethernet Cable
- Mounting Hardware
2 Mounting Brackets
1 Quick Install Guide

Parts not provided with the EXTender

•
Digital telephones and communication line cords are NOT supplied with this system.
Note: Use two-wire digital telephones only.
•
Punchdown blocks necessary to interface between the RJ-21 connector and the remote telephones.
•
50 pin cable with male RJ-21 connectors to interface between the punchdown block and the
EXTender. (See Pin Out Assignments on page 14)
•
Analog telephone line for local use, if you purchased an analog line card.
Note: The analog line card is not available outside North America.

Installation Considerations

•
The system operates from 100-240 VAC, 50-60 Hz. Do not apply power to the unit until instructed to
in the installation procedures.
•
Install the power supply and cabling away from high power/high RF noise devices such as computers,
fans, fluorescent ballast, or power supplies.
•
Use good wiring practices. Do not run wires over fluorescent lights, computers, air conditioners, etc.,
as this can introduce noise to the modems.
•
The distance from the telephones to the EXTender should NOT exceed 500 feet.
EXTender 6000 Quick Installation Guide 11
