Device Error Control System - Signode BXT 2 Maintenance Manual

BXT 2 BXT 2-19
24
12.2.

Device Error control system

Error Reports in conjunction with the control system.
System error
Nr.
E10 DEVICE_UNKNOWN_DEVICE Description:
E11 DEVICE_WRONG_BATTERY
E12 DEVICE_KEYPAD_ERROR
E13 DEVICE_ORIGIN_ERROR
ak 3.11
Description
Device Type (14,4V, 18V) could not be detected
Possible cause:
•
Wrong type of PCB (14,4 / 18V)
•
Wrong Firmware. (The Firmware does not support this
tool type.
•
Hardware failure when reading coding resistors
Rectification:
1. Try again, unplug and plug the battery
2. Replace PCB (Pos.198)
Description:
Plugged Battery is known but not valid (Wrong voltage)
Possible cause:
•
Wrong battery type.
•
Wrong type of PCB
•
Hardware failure on the power electronics.
Rectification:
1. Replace battery
2. Replace PCB (Pos. 198)
Description:
Keypad reports consistent pressure on keys
Possible cause:
•
Keys are pressed consistent
•
Keypad is defective
Rectification:
1. Release keypad
2. Replace Keypad
3. Replace PCB, (Pos. 198)
Description:
Error at cam switch (Pos. 103)
Possible cause:
•
Defective cam switch. (always on/off)
Behebung:
1. Pull rocker lever to reset cam switch
2. Check cables and connections to cam switch
3. Replace cam switch
4. Replace PCB, (Pos 198)
System reaction
Stop
The tool is switched off.
Stop
The tool is switched off.
Interruption
Current process is
interrupted. Tool goes in
standby mode again.
Interruption
Current process is interrupted.
Tool goes in standby mode
again.
