3.2.
Connections to the factory monitor control-box
Connect the interface LVDS cable to the video-interface.
Remove the female 22pin Mitsumi LVDS connector from the rear of the factory
monitor control-box and connect it to the male 22pin Mitsumi LVDS connector of the
video-interface.
Connect the female 22pin Mitsumi connector of the interface LVDS cable to the male
22pin Mitsumi LVDS connector of the factory monitor control-box.
Version 19.10.2012
