1.1.2. Rear-view camera settings (dip 5)

Depending on whether no camera, after-market camera or factory camera shall be used, dip
5 must use different settings.
If set to OFF, the interface switches to factory LVDS picture when the
reverse gear is engaged to display factory rear-view camera or
factory PDC picture. The green wire of the video-interface's 6pin
power connector must be connected to reverse light (+12V of
reverse light signal) by using a relay, ONLY if camera (after-market or
factory) shall is (to be) installed (Relay AC-RW1230 and AC-RS5
optionally available).
Version 19.10.2012
Rear-view
Dip 5
camera type
None OFF
Factory OFF
After-market ON
C2-MMi2G-x
