ADSP-BF706 EZ-KIT Mini Hardware Reference

USB Connector (P8)

Part Description
USB Micro-AB
USB Micro-B to Standard-A or
Micro-A to Standard-A receptacle
cable

USB Connector (ZP1)

Part Description
USB Mini-B
USB Mini-B to Standard-A cable

Audio Connectors (J1-2)

Part Description
3.5 mm stereo jack
3.5 mm cable, headphone cable
ADSP-BF706 EZ-KIT Mini Evaluation System Manual
Manufacturer Part Number
Hirose ZX62D-AB-5P8
Mating Cable
Any
Manufacturer Part Number
DIGI-KEY H11589CT-ND
Mating Cable
Any
Manufacturer Part Number
DIGI-KEY CP1-3515SJGRTR-ND
Mating Connector
Any
2-9
