3.6.19 SigmaStudio Connector (P2)

This connector interfaces with SigmaStudio through the EVAL-ADUSB2EBZ board. The connector
is a 0.1" header. The pinout can be found in

3.6.20 JTAG Connector (P3)

The JTAG header (P3) provides debug connectivity for the processor. This is a 0.05" shrouded
through-hole connector from SAMTEC (SHF-105-01-L-D-SM-K). This connector mates with ICE-
1000, ICE-2000, and any newer Analog Devices emulators. For more information, see
.

3.6.21 TRACE and JTAG Connector (P7)

The TRACE and JTAG connector (P7) provides connectivity to the processor's trace interface. This is
a MICTOR connector from TYCO (2-5767004-2). At this time, there are no trace pods available.

3.6.22 USB to UART Connector (P8)

Part Description
USB Micro-AB
Mating Cable
USB Micro-B to Standard-A cable
3.6.23 USB Connectors (P10–P11)
Part Description
USB Micro-AB
Mating Cable
USB Micro-B to Standard-A or Micro-A to Standard-A receptacle cable
ADSP-SC589 EZ-Board® Evaluation System Manual
Appendix B - Schematics
Manufacturer Part Number
Hirose ZX62D-AB-5P8
.
Debug Interface
Manufacturer Part Number
Hirose ZX62D-AB-5P8
46
