A ADSP-BF706 EZ-KIT MINI BILL
OF MATERIALS
The bill of materials corresponds to the
Schematic.
Ref. Qty. Description
1 1 ADP171AUJZ
SOT95P280-5N
2 2 ADP7102ARDZ-3.3
SOIC127P600-9N
3 1 ADM6384YKS29D1Z
SC70_4
4 1 ADAU1761
QFN50P500X500-33N
5 1 ADSP-BF706
QFN50P1200X1200-89N
6 5 10UF 6.3V 10% 0805
X5R
7 8 0.1UF 10V 10% 0402
X5R
8 13 0.01UF 16V 10% 0402
X7R
9 7 0.1UF 16V 10% 0603
X7R
10 1 0.033UF 25V 10% 0603
X7R
ADSP-BF706 EZ-KIT Mini Evaluation System Manual
ADSP-BF706 EZ-KIT Mini
Reference
Designator Manufacturer
VR3 ANALOG
DEVICES
VR1,VR2 ANALOG
DEVICES
U3 ANALOG
DEVICES
U2 ANALOG
DEVICES
U1 ANALOG
DEVICES
C31,C32,C36,C37, AVX
C40
C1,C6,C8-C10,C15, AVX
C17,C21
C11-C14,C18-C20, AVX
C22,C23,C26,C42,
C43,C45
C34,C35,C38,C39, AVX
C41,C44,C54
C53 AVX
Part Number
ADP171AUJZ-R7
ADP7102ARDZ-3.3-R7
ADM6384YKS29D1Z
ADAU1761BCPZ-R7
ADSP-BF706BCPZ-ENG
08056D106KAT2A
0402ZD104KAT2A
0402YC103KAT2A
0603YC104KAT2A
06033C333KAT2A
A-1
