2. Use the Debug Configurations wizard to connect to the EZ-KIT
Mini board.
If a debug configuration exists already, select the appropriate
configuration and click Debug. Go to step 8.
To create a debug configuration, do one of the following:
• Click the down arrow next to the bug icon
Debug Configurations.
• Choose Run > Debug Configurations.
The Debug Configuration dialog box appears.
3. Select CrossCore Embedded Studio Application and click
(New launch configuration).
The Select Processor page of the Session Wizard appears.
4. Ensure Blackfin is selected in Processor family. In Processor type,
select ADSP-BF706. Click Next.
The Select Connection Type page of the Session Wizard appears.
5. Select EZ-KIT and click Next.
The Select Platform page of the Session Wizard appears.
6. Choose the default ADSP-BF706 EZ-KIT via Debug Agent.
7. Click Finish to close the wizard.
The new debug configuration is created and added to the Debug
Configurations list.
ADSP-BF706 EZ-KIT Mini Evaluation System Manual
Using ADSP-BF706 EZ-KIT Mini
, select
1-5
