Recovery - Image Access WideTEK 36CL Setup Instructions

Checking height adjustment and document transport
➢ Place the object in the center and check the transport by pressing the
two buttons for document transport on the operating screen.
The object should move backwards and forwards evenly and without
resistance.
➢ The object must always be supported by the user.
This applies to both the feeding and the ejection at the end of the scanning
process.
If the object turns to the left during transport, the pressure on the right
side is too low.
If the object rotates to the right, the pressure on the left side is too low.
➢ Change the pressure on the object with the two adjusting screws (2).
If the object cannot be moved backwards and forwards or if it sticks to the
rear, the pressure is too high.
Test scan
➢ Now insert the item back into the machine for scanning.
➢ In ScanWizard, from the "Transport / Transport Speed" menu, select the
"Thick Documents" function.
➢ Start a scan.
The height adjustment was successful if the scanned item was transported
straight during the scan process, without any resistance, and the resulting
image does not have any image errors.

Recovery

Solid State Disk Software Error
The file system and Linux operating system of a Scan2Net scanner are very
robust and fault tolerant. The file system is capable of repairing itself even
if the system loses power during a hard drive write, which would almost
certainly damage any Windows, Android, or MAC operating system based
computer. However, it is still possible for the Scan2Net Linux software on
the SSD to become corrupted under certain circumstances. Unexpected
power outages, hard shutdowns via the main power switch without a prior
controlled shutdown, and other unexpected interruptions to the operating
system can cause this type of disruption. In addition, any uncontrolled
Perform setup
