NetBackup 5220 rear panel

Bezel

Check the optional bezel on the front panel of the NetBackup 5220. The black
molded-plastic bezel protects the front panel from damage or accidental contact.
Proper air flow through the chassis may be impeded if there are problems with the
bezel.
Verify that the bezel is:




NetBackup 5220 AC power connections

Verify that both AC power cables are connected properly.

AC power cable connections of the NetBackup 5220 (rear view)

Checking the Symantec Storage Shelf

Verify that the physical exterior of the device is intact, clean, and in proper working
condition.
Securely attached to the front panel
Not damaged
Not obstructed or blocked
31
