TOP VIEW
6
5
4
3
2
1
(1) High beam indicator
(2) Ignition switch with key
(3) Horn switch
(4) Turn signal switch
(5) Clutch lever
(6) Rear view mirrors
(7) Pass lamp switch
(8) LCD panel of Meter console. refer
instruments and indicators (page 17)
for fuel gauge, speedometer and other
features of console
(9) Side stand indicator
(10) Left turn signal indicator
*Accessories and features shown may not be part of standard fitment.
9 10 11 12 13
7
8
14
15
(11) Neutral indicator
(12) Right turn signal indicator
(13) Programmed FI malfunction indicator
lamp (MIL)
(14) Mode (M) and Set (S) buttons
(15) Front brake master cylinder/Reservoir
(16) Engine stop/kill switch
(17) Front brake lever
(18) Throttle grip
(19) Electric starter switch
(20) ABS indicator
(21) Fuel tank cap
4
16
17
18
19
20
21
