HERO MAESTRO EDGE Owner's Manual
  1. Manuals
  2. Brands
  3. HERO Manuals
  4. Motorcycle
  5. MAESTRO EDGE
  6. Owner's manual

HERO MAESTRO EDGE Owner's Manual

Hide thumbs Also See for MAESTRO EDGE:
Table of Contents

Advertisement

Quick Links

PREFACE
No: IB9A
MAESTRO EDGE vehicle. We wish you many
Thank you for selecting a
Hero MotoCorp
miles of continued riding pleasure in the years ahead.
We, at
, are committed to demonstrate excellence in our environment
Hero MotoCorp
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with all applicable environment legislation and strengthen the green
supply chain.
This booklet is your guide to the basic operation and maintenance of your new
MAESTRO EDGE vehicle. Please take time to read it carefully. As with any
Hero MotoCorp
fine machine, proper care and maintenance is essential for trouble-free operation and
optimum performance.
Your Authorised Distributor and Dealer(s) of the Distributor ("Dealer") will be glad to provide
further information or assistance and is equipped to handle your future service needs.
Let us make this world a safer, healthier and more environment friendly place.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAESTRO EDGE and is the answer not in the manual?

Questions and answers

Sheeja G
March 21, 2025

Why is engine malfunction light on while scooter is running and is it safe to ride if the light is on

0
1 comments:
Mr. Anderson
March 21, 2025

The engine malfunction light (Immobilizer/Malfunction indicator) on the HERO MAESTRO EDGE scooter turns on continuously and starts blinking after 10 seconds if there is a malfunction in the immobilizer system. This indicates a potential issue with the ignition system, which prevents the engine from starting without an authorized key.

It is not safe to ride with the light on, as it may indicate a serious issue with the scooter's security or electrical system. The manual advises contacting an authorized workshop for inspection and repair if this occurs.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for HERO MAESTRO EDGE

Summary of Contents for HERO MAESTRO EDGE

  • Page 1 This booklet is your guide to the basic operation and maintenance of your new MAESTRO EDGE vehicle. Please take time to read it carefully. As with any Hero MotoCorp fine machine, proper care and maintenance is essential for trouble-free operation and optimum performance.
  • Page 2 AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED. RESERVES THE RIGHT TO MAKE CHANGES IN ITS Hero MotoCorp Ltd CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY...

  • Page 3: Table Of Contents

    î î Immobilizer BASIC TROUBLESHOOTING î Side stand indicator DELIVERY CERIFICATE î Side stand switch/side stand (Optional) HERO GENUINE PARTS î Pillion footrest JOBS APPLICABLE TO PERIODIC SERVICES î BODY PARTS REMOVAL SERVICE RECORD SHEET Center compartment SERVICE ADVICE SHEET î...

  • Page 5: Vehicle Identification

    Year of Month of Assembly Plant Serial Number Description Manufacturing Manufacturing Model: Maestro EDGE Engine Variant Cast wheel/Integrated brakes VIN and Engine number may be required: 1. During registration of the vehicle. 2. For dealing with Legal & Insurance Departments.

  • Page 6: Vehicle Specification

    VEHICLE SPECIFICATION ITEM SPECIFICATIONS Dimensions Overall length 1841 mm Overall width 695 mm Overall height 1190 mm Wheelbase 1261 mm Saddle height 775 mm Ground clearance (Under cover) 155 mm Weight Kerb weight 110 Kg Capacities Engine oil 0.80 litre at disassembly and 0.70 litre at draining 0.12 litre at disassembly Transmission oil 0.10 litre at draining...
  • Page 7 VEHICLE SPECIFICATION ITEM SPECIFICATIONS Internal expanding shoe type (Dia. 130 mm) Front/Rear brake Drum type (Integrated braking) Transmission Primary reduction Variomatic drive, (2.53-0.8) 9.423 (50/20X49/13) Final reduction Clutch system Dry, Automatic Centrifugal Clutch Electricals Battery 12V-4Ah ETZ-5 *MF Battery 123 W Alternator Starting System Kick/Electric Start...

  • Page 8: Vehicle Safety

    Hero MotoCorp handles, and to become accustomed to the vehicle. See (page 7) for more details. vehicle's size and weight.

  • Page 9: Protective Apparel

    If you are involved in a crash WARNING Personal safety is your first priority. If you or Not wearing a helmet increases the chance of î anyone else has been injured, take time to serious injury or death in a crash. assess the severity of the injuries and whether Be sure you and your pillion always wear a î...
  • Page 10 PROTECTIVE APPAREL Always wear HELMET Wear a face shield or goggles Wear bright or reflective clothing Wear gloves Shoes should be close fitting, low heels and offer ankle protection...

  • Page 11: Load Limits And Guidelines

    However exceeding the weight limit or carrying an unbalanced load can seriously affect your vehicle's handling, braking and stability. Non accessories, Hero MotoCorp modifications, and poor maintenance can reduce your safety margin. The following pages give more specific information on loading, accessories and modifications.

  • Page 12: Accessories And Modifications

    Accessories We strongly recommend that you use only genuine accessories that Hero MotoCorp have been specifically designed and tested for your vehicle. cannot test all Hero MotoCorp other accessories, you must be personally responsible for proper selection, installation and use of non accessories.

  • Page 13: Tips For Healthy Environment

    Hero MotoCorp incompatible spares and accessories can upset or deteriorate your vehicle’s running condition. Genuine engine oil: Hero 4T Plus SAE 10W 30 SJ grade (JASO MA) engine oil î recommended by and make sure you change it every 6000 km (with Hero MotoCorp top up every 3000 kilometres) to keep the engine fit and environment healthy.

  • Page 14: Vehicle Views

    VEHICLE VIEWS TOP VIEW 9 10 (1) Turn signal indicator (11) Speedometer (2) Choke knob (12) Fuel gauge (3) Horn switch (13) Service reminder (4) Turn signal switch (14) Immobilizer/Malfunction indicator (5) Integrated brake lever (15) Tripmeter (6) Parking lever (16) Front brake lever (7) Rear view mirror (17) Throttle grip...
  • Page 15 VEHICLE VIEWS LEFT SIDE VIEW (1) Side stand switch (optional) (5) Kick starter pedal (9) Rear grip (2) Side stand (optional) (6) Women pillion step (optional) (10) Boot lamp (inside) (3) Main stand (7) Rear turn signal lamp (11) Seat (4) Pillion step (8) Tail/stop lamp (12) Rear luggage hook...
  • Page 16 VEHICLE VIEWS RIGHT SIDE VIEW (1) Exhaust muffler (5) Front turn signal lamp (8) USB charger (inside) (2) Oil level dipstick (6) Position lamp (9) Center compartment (inside) (3) Pillion step (7) Front luggage hook (10) Rear reflex reflector (4) Front inner box (optional) Accessories and features shown may not be part of standard fitment.

  • Page 17: Part Functions

    PART FUNCTIONS Instruments and Indicators The indicators are in the speedometer panel above the headlamp. The functions are as below. Description Sl. No. Function Side stand indicator Light glows when the vehicle is parked on the side stand. High beam indicator Light glows when headlamp is in Hi Beam.

  • Page 18: Odometer/Tripmeter

    LCD PANEL If all the vertical bars (2) are displayed it ODOMETER/TRIPMETER means fuel quantity in the fuel tank is 5.5 litres. The odometer (1) shows accumulated distance traveled. The tripmeter (2) shows distance traveled since trip meter was reset last time. Tripmeter displays upto 999.9 km If the tripmeter exceeds "999.9"...

  • Page 19: Keys

    KEYS This vehicle has two keys and a key number plate. (1) Service reminder (1) Keys (2) Key number plate TOTAL You will need the key number if you ever have Indicator DISTANCE to replace a key. Store the plate in a safe Behaviour place.

  • Page 20: Major Components

    MAJOR COMPONENTS brake starts to engage is called free play (3). Measured at the tip of brake levers, free play (Information you need to operate this vehicle) should be maintained at 10-20 mm. BRAKES (Integrated braking) Adjustment Brakes are items of personal safety and should Right hand front brake cable (A) on “1”...

  • Page 21: Fuel

    If the free play is more than 20 mm further turn î the adjuster nut to obtain desired free play. Make sure the cut-out on the adjusting nut (1) is seated on the brake joint pin (2) after making final free play adjustment. ü...
  • Page 22 We recommend that you use unleaded petrol To open the fuel filler cap (2), insert the because the muffler in the vehicle is fitted with ignition key (3), push it in and turn the a catalytic convertor, it also produces lesser ignition key to “FUEL OPEN”...

  • Page 23: Tyres (Tubeless)

    Failure to do so is considered misuse, and damage caused by misuse is not covered under WARNING warranty policy. Hero MotoCorp Petrol is highly flammable and explosive. î Petrol containing alcohol You can be burned or seriously injured when handling fuel.
  • Page 24 Air pressure Keeping tyres properly inflated provides the best combination of handling, tread life and riding comfort. Generally, under-inflated tyres wear unevenly, adversely affect handling and are more likely to fail from being overheated. Over-inflated tyres make your vehicle ride harshly are more prone to damage from road hazards and wear unevenly.
  • Page 25 Excessive tread wear. î (1) Tyre wear indicator (2) Arrow mark Unidirectional tyres Carefully inspect the tyres for any damage, î Whenever the tyre is removed and put back in if the vehicle hits a pothole or hard object. case of puncture, ensure the arrow mark (2) Tread wear on the tyre is in the same direction as that of Replace tyres immediately when the wear...
  • Page 26 NOTE You should not exceed 70 km/hour for the 1st 24 hours or 105 km/hour at any time For repair and replacement of tyre it is advised thereafter. In addition you may not be able to to visit your Authorised Distributor/Dealer. safely carry as much load as with a new tyre.

  • Page 27: Essential Individual Components

    ESSENTIAL INDIVIDUAL COMPONENTS IGNITION SWITCH The ignition switch (1) is on the right side below the steering. “FUEL OPEN” Position “ON” ( ) Position (1) Ignition switch “OFF” ( ) (2) Ignition key Position/Lock Open (3) Steering lock position (4) Seat open “SEAT OPEN”...

  • Page 28: Right Handlebar Controls

    RIGHT HANDLEBAR CONTROLS 3. Horn switch ( ) Starter switch ( ) Press the switch to operate the horn. The starter switch (1) is next to the throttle grip. When the starter switch is pressed, the starter motor cranks the engine. See (page 39) for the starting procedure.

  • Page 29: Fuel Tank Lid Lock

    To open the seat, insert the key (2) and turn CAUTION it counterclockwise to “SEAT OPEN” Do not try to turn the key to "LOCK" position position. The seat will release from its catch. while riding the vehicle, which may lead to loss To lock the seat, close and push down on the of vehicle control.

  • Page 30: Center Compartment

    Remove the helmet from the holder and î close the seat. WARNING Riding with a helmet attached to the holder î can interfere with the objects and could cause a loss of control/crash in which you can be seriously hurt. Use the helmet holder only while parked.

  • Page 31: Boot Lamp/Boot Lamp Switch

    Use of non-standard USB cable may cause kept inside the center compartment should be damage to the mobile phones. removed to prevent consequential damage. Hero will not be responsible for damages BOOT LAMP MotoCorp caused due to use of non-standard USB cable.

  • Page 32: Rear Luggage Hook

    REAR LUGGAGE HOOK NOTE Rear luggage hook is located below the front Do not apply any soap solution, oil or î end of the seat. To use the hook, turn the hook grease inside the mobile charging port. from its position and open the hook by turning Any personal belongings have to be î...

  • Page 33: Immobilizer

    In normal conditions, once the ignition key is IMMOBILIZER turned “ON”, the lamp glows and goes “OFF” immediately. Your MAESTRO EDGE vehicle is provided with an immobilizer system. This is an anti- theft device built into the ignition system, which prevents the engine to start without an authorised key.

  • Page 34: Side Stand Indicator

    If there is a malfunction in the Immobilizer Do not play with ignition key as quick turn · system, the Immobilizer/Malfunction “OFF” and turn “ON” , vigorously, this may result in to false indication in Immobilizer indicator (1) would glow continuously and and in Immobilizer/Malfunction indicator start blinking after 10 seconds after the lamp.

  • Page 35: Pillion Footrest

    (1) Left footrest (2) Side stand switch (3) Side stand spring Check the side stand for proper function î and the spring (3) for damage or loss of tension and the side stand assembly for free movement. Check whether the side stand indicator (1) î...

  • Page 36: Body Cover

    NOTE Park the vehicle on its main stand when servicing the vehicle with the center compartment removed. Body cover Removal Remove the center compartment (page 31). î Remove the tray fuel sub assembly bolt (1). î (1) Bolts Slightly lift up the center compartment î...
  • Page 37 Remove the screws (3) from the center Remove the screws (6). î î cover. Remove the center cover. î (6) Screws (3) Screws (4) Center cover Remove the screws (7) from left and right î side of the body cover. Remove the screws (5).
  • Page 38 Remove the body cover bolts (8). Disconnect the tail/stop lamp connector î î (10). (8) Body cover bolts (10) Tail/stop lamp connector Disconnect the fuel tank lid lock cable (9). î Disconnect the drain tube from the joint î (11). (9) Fuel tank lid lock cable (11) Drain tube Remove the fuel filler cap (page 18).

  • Page 39: Front Center Cover

    Pull the body cover (12) slightly backwards Remove the two screws (2) near the front î î and carefully remove the tabs (13) from fender. the slots. (2) Screws Remove the complete body cover. î Release the front center cover lugs (3) from Installation the mounting clips.
  • Page 40 Front cover Remove the screws (4) from the floor side î covers. Removal Remove the front center cover (page 35). î Remove the four screws (1) on the inner î cover side and remove two screws from front inner box. Remove front inner box. (4) Screws Remove the left and right front covers and î...
  • Page 41 Rear view mirror Headlamp case Removal Removal Remove the rear view mirror. Slide the dust cover up (1). î î Remove screw (1). Loosen the lock nut (2) until it will no î î longer turn. Loosen the rear view mirror (3) and î...

  • Page 42: Headlamp Focus

    Park the vehicle on main stand on a î level surface in front of a wall. Loosen the bolt (1) and move the î headlamp up or down for correct focus. WARNING An improperly adjusted headlamp may blind oncoming driver or it may fail to light the road for safe distance.
  • Page 43 Lamps and horn-Check that headlamp, NAME : _______________________________ î tail/stop lamp, turn signal lamps, indicators ADDRESS : ___________________________ and horn function properly. _______________________________________ Rear view mirror-Ensure that the rear î _______________________________________ view mirror gives a good rear view when _______________________________________ you are sitting on the vehicle.
  • Page 44 Turn the ignition switch (3) to "ON". î CAUTION Do not attempt to start the engine and run the vehicle without a battery. This may lead to electrical and electronic components failure. Park the vehicle on its main stand. î Lock the rear wheel by pressing the î...
  • Page 45 RUNNING-IN Ensure your vehicle's future reliability and performance by paying extra attention to how you ride during the first 500 km. During this period, avoid full-throttle starts and rapid acceleration. RIDING Review vehicle Safety (page 4) before you ride. (4) Choke knob (A) Fully “ON”...
  • Page 46 (1) Integrated brake lever (2) Parking lever Mount the vehicle from the left side î keeping at least one foot on the ground to steady the vehicle. Before starting, indicate your direction with î the turn signals, and check for safe traffic Unlock the integrated brake by further î...
  • Page 47 When slowing down the vehicle, î coordination of the throttle (3), front (4) and integrated brake (5) is most important. CLOSE To accelerate, open the throttle (3) î gradually, the vehicle will move forward. Do not "BLIP" the throttle (open and close rapidly) as the vehicle will move forward Since the vehicle is equipped with an suddenly, causing possible loss of control...
  • Page 48 When approaching a corner or turn, After completing the turn, open the î î close the throttle (3) fully, and slow down throttle gradually to accelerate the the vehicle by applying integrated brake vehicle. (6). CLOSE (3) Throttle (5) Front brake (6) Integrated brake...
  • Page 49 When descending a steep gradient, Avoid continuous use of the brakes, which î may result in overheating and reduction of close throttle (3) fully and apply integrated braking efficiency. brake (4) to slow down the vehicle. CLOSE (3) Throttle (4) Integrated brake...
  • Page 50 When riding on wet or loose surfaces, î HOW TO USE MAIN STAND be cautious. When riding in wet or rainy conditions or on loose surfaces, the ability to manoeuvre and stop will be reduced. For your safety: Exercise extreme caution when braking, î...

  • Page 51: Tool Kit

    TOOL KIT MAINTENANCE The tool kit (1) is located in the center IMPORTANCE OF MAINTENANCE compartment (2). A well-maintained vehicle is essential for safe, Some roadside repairs, minor adjustments and economical and trouble-free riding. It will also parts replacement can be performed with the help reduce air pollution.
  • Page 52 Remember that your Authorised Distributor/ Dealer knows your vehicle best and is fully equipped to maintain and repair it. To ensure best quality and reliability, use only Genuine Parts for Hero MotoCorp repair and replacement.

  • Page 53: Maintenance Schedule

    The following Maintenance Schedule specifies all maintenance required to keep your vehicle in peak operating condition. Maintenance work should be performed in accordance with standards and specifications of Hero by properly trained and equipped technicians. Your Authorised Distributor/Dealer meets all of MotoCorp these requirements.
  • Page 54 MAINTENANCE SCHEDULE Dear Customer, We would strongly recommend the following schedule, to keep your vehicle in perfect running condition and healthy environment. vehicle subjected to severe use or ridden in dusty area will require more frequent servicing. SERVICE ITEMS Next Next Next Next...
  • Page 55 SERVICE ITEMS Next Next Next Next Next Next Next Next Next Next 1st 60 DAYS NOTE- 500- 3000- 6000- 9000- 12000- 15000- 18000- 21000- 24000- 27000- 30000- 3500 6500 9500 12500 15500 18500 21500 24500 27500 30500 Brake Shoe Wear Parking Lock Operation Battery Voltage NOTE-10...

  • Page 56: Air Cleaner

    AIR CLEANER Air cleaner cleaning î Remove the air cleaner element (4) Refer to the safety precautions (page 48). from housing (5). The air cleaner element is of Dry Paper Pleated type, it should be serviced at regular intervals (pages 49). Service more frequently when riding in unusually wet or dusty areas.

  • Page 57: Throttle Operation

    Free Play Adjustment Install the air cleaner element. î Slide the grommet (2), loosen the lock nut Install the removed parts in the reverse î (3) and turn the adjuster (4). order of removal. CAUTION Never wash the air cleaner element. Only î...

  • Page 58: Drain Tube/Engine Oil

    (1) Air cleaner element housing cover (2) Screw (1) Drain tube (2) Air cleaner assembly ENGINE OIL Use only Hero Genuine Engine Oil. BRAND : Hero 4T plus GRADE : SAE 10W 30 SJ Grade (JASO MA). Manufactured by: Tide Water Oil Co.

  • Page 59: Engine Oil Replacement/Oil Strainer Cleaning

    Remove the oil level dipstick. Stop the engine and park the vehicle î î on the main stand on a level surface. Place an oil drain pan under the crankcase î and remove the oil drain bolt (1). After a few minutes, remove the oil level î...

  • Page 60: Final Drive Oil Replacement

    WARNING Please dispose used engine oil in a manner î that is compatible with the environment. We suggest you take it in a sealed container to your local recycling center or service station for reclamation. Do not throw it in the trash or pour it on the ground or down a drain.

  • Page 61: Spark Plug

    (1) Noise suppressor cap (1) Check bolt (2) Drain bolt Disconnect the noise suppressor cap (1) î Fill the transmission case with î from the spark plug. recommended oil through the check bolt Clean any dirt around the spark plug base. î...
  • Page 62 With the plug washer attached, thread the î Adjust idle speed by adjusting the throttle î spark plug in by hand to prevent cross- stop screw (1) by inserting a suitable screw threading. driver. Tighten a new spark plug 1/2 turn with a î...

  • Page 63: Battery

    Rear brake This symbol on the battery means the old battery must be returned to your Authorised Distributor/Dealer as it must be treated as recyclable material. Battery is a Maintenance-Free (sealed) type and can be permanently damaged if the sealing strip is removed. An improperly disposed battery can be harmful to the environment and human health.

  • Page 64: Fuse Replacement

    Ensure the battery leads are properly connected î to the battery terminals during installation. Battery Removal Remove the front center cover (page 35). î Remove the battery band (1) from the boot î band clip (2). (5) Battery Remove the battery (5). î...

  • Page 65: Side Stand

    If the replacement fuse of the same rating î burns out in a short time, there is probably a serious electrical problem on your vehicle. Leave the blown fuse in that circuit and have your vehicle checked by your Authorised Distributor/Dealer.
  • Page 66 Front Rear (2) Side stand indicator BULB REPLACEMENT Refer to the Safety Precautions (page 48). CAUTION The bulb becomes very hot while the lamp is Ensure that adequate care should be taken “ON”, and remains hot for a while after it is while cleaning the side stand switch.
  • Page 67 Headlamp/Position lamp bulb Remove the headlamp bulb (5) without î Remove the headlamp case (page 37). turning. î Remove the position lamp bulb (6) from î both sides of the headlamp case. (1) Headlamp connector (2) Position lamp connector Disconnect the headlamp connector (1) î...

  • Page 68: Cleaning Of Vehicle

    Install a new bulb in the reverse order of î removal. Front turn signal bulb Insert hand from body cover front side, î above front fender area and remove turn signal bulb holder (1) by turning counter clockwise. Remove the bulb (1) by turning it to î...

  • Page 69: Washing Of Vehicle

    If your vehicle is still warm from recent After cleaning, rinse the vehicle î operation, give time for the engine and thoroughly with plenty of clean water. exhaust system to cool down. Strong detergent residue can corrode We recommend avoiding the use of high alloy parts.

  • Page 70: Polishing Of Vehicle

    Wash your vehicle when run on such conditions by the following the point mentioned below, Clean the vehicle using cold water (page 65). Do not use warm water. This worsens the effect of the salt. STORAGE GUIDE Extended storage, such as for winter, requires that you take certain steps to reduce the effects of deterioration from non use of the vehicle.
  • Page 71 Removal from storage To prevent rusting in the cylinder, perform î the following: Uncover and clean the vehicle. Change the î engine oil if the vehicle has been stored for Remove the noise suppressor cap from · more than 4 months. the spark plug.

  • Page 72: Air Suction Valve

    Air suction valve (1) Air Suction Valve Further to meet emission standards this vehicle is provided with the air suction valve. Air Suction Valve (1) supplies fresh air from the air filter to the exhaust manifold to convert carbon monoxide to carbon dioxide. This reduces the CO% in the vehicle's exhaust.

  • Page 73: Basic Troubleshooting

    BASIC TROUBLESHOOTING 1. STARTING TROUBLE - ENGINE DOES NOT START A. Fuel System Check fuel in fuel tank Refill No fuel Rectify Check fuel lines Leakage/air lock Consult Authorised Distributor/Dealer B. Electric Starter Not Working Replace fuse (ref. Page 60) Check fuse Fused Inspect battery...
  • Page 74 BASIC TROUBLESHOOTING 3. POOR PICK UP Spark plug loose in cylinder head Tighten the spark plug Loose Check air cleaner element Clean & Refit Dirty/Clogged Check brake binding Readjust free play of rear brake lever Improper Adjustment Check tyre inflation pressure Correct tyre pressure Under inflated Consult Authorised Distributor/Dealer...

  • Page 75: Delivery Cerificate

    Hero MotoCorp Ltd. DELIVERY CERTIFICATE IB9A No.: DEALER CODE MAESTRO EDGE I certify having taken delivery of one Hero MotoCorp vehicle bearing the following particulars:- Engine No. VIN No. Colour/Model Key No. Allotment No. Date of Sale Customer’s Name I have been explained by the dealer about correct and safe driving habits, warranty terms and conditions, service schedules and maintenance tips.
  • Page 76 Hero MotoCorp Ltd. Alongwith the vehicle I have also received the following:- 1. Owner’s Manual 2. 2 Nos. Keys 3. 1 Set of tools (for details see below) 4. Standard Accessories 5. Battery Make Sr. No. 6. Tyre Front Make Sr.
  • Page 77 Hero MotoCorp Ltd. DELIVERY CERTIFICATE IB9A No.: DEALER CODE MAESTRO EDGE I certify having taken delivery of one Hero MotoCorp vehicle bearing the following particulars:- Engine No. VIN No. Colour/Model Key No. Allotment No. Date of Sale Customer’s Name I have been explained by the dealer about correct and safe driving habits, warranty terms and conditions, service schedules and maintenance tips.
  • Page 78 Hero MotoCorp Ltd. Alongwith the vehicle I have also received the following:- 1. Owner’s Manual 2. 2 Nos. Keys 3. 1 Set of tools (for details see below) 4. Standard Accessories 5. Battery Make Sr. No. 6. Tyre Front Make Sr.
  • Page 79 WHAT ARE THE BENEFITS OF Hero MotoCorp GENUINE SPARE PARTS ? Assures long life î Ensures economy for a long time î Safety of vehicle and rider î Peace of mind î Value for money î Assured quality î CONSEQUENTIAL DAMAGES ON USING NON-GENUINE PARTS Poor performance î...

  • Page 80: Jobs Applicable To Periodic Services

    Hero MotoCorp Ltd. JOBS APPLICABLE TO PERIODIC SERVICES Test drive the vehicle if required for reported troubles, if any. î Wash the vehicle and blow dry with air at every service. î Inspect fuel lines at every service. î Inspect throttle free play and operation, at every service, adjust if necessary.

  • Page 81: Service Record Sheet

    SERVICE RECORD SHEET To be Filled in by Supervisor Engine Oil Authorised Free/Paid Job Card Km. Range Top-up/ Distributor/Dealer Date Reading Service (Sig. & Stamp) Replace 500 - 750 3000 - 3500 6000 - 6500 9000 - 9500 12000 - 12500 15000 - 15500 18000 - 18500 VIII...
  • Page 82 SERVICE RECORD SHEET To be Filled in by Supervisor Engine Oil Authorised Free/Paid Job Card Km. Range Top-up/ Distributor/Dealer Date Reading Service Replace (Sig. & Stamp) XVIII 51000 - 51500 54000 - 54500 57000 - 57500 60000 - 60500 XXII 63000 - 63500 XXIII 66000 - 66500...

  • Page 83: Ownership Record And Data

    Hero MotoCorp Ltd. OWNERSHIP RECORD AND DATA NAME__________________________________________________________________________ ADDRESS______________________________________________________________________ MODEL_______________________________ REGN. NO. ______________________________ ENGINE NO.__________________________VIN NO.__________________________________ DATE OF PURCHASE____________________KM. READING _________________________ AUTHORISED DISTRIBUTOR/DEALER NAME_________________________________ ADDRESS______________________________________________________________________ _________________________________________________________________________________ BATTERY MAKE_______________________ SERIAL NO._____________________________ AUTHORISED DISTRIBUTOR/DEALER STAMP AND SIGNATURE...
