LEFT SIDE VIEW
16
(1) Side reflex reflector
(2) Front hugger fender
(3) Starter motor
(4) Gear shift pedal
(5) Rider footrest
(6) Main stand (optional)
*Accessories and features shown may not be part of standard fitment.
1
2
3
(7) Side stand
(8) Pillion foot rest
(9) Saree guard
(10) Seat lock
(11) Rear grip
15
14
13
4
5
6
7
(12) Seat
(13) Left side cover
(14) Battery compartment (inside)
(15) Side stand switch
(16) Front fender
5
12
11
10
8
9
