INSTRUMENTS AND INDICATORS

The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
Description
Sl. No.
1
Tachometer
2
Side stand indicator
3 Turn signal indicator (L) Flashes when left turn signal switch is operated.
High beam indicator
4
5
Neutral indicator
Anti-lock braking
6
system (ABS)
indicator
Turn signal indicator (R) Flashes when right turn signal switch is operated.
7
1
17
Shows engine revolution per minute. The tachometer
digital segments will swing to maximum scale on the meter
console once the ignition switch is turned "ON" .
Light glows when the vehicle is parked on the side stand.
Light glows when headlamp is in high beam.
Light glows when vehicle is in neutral.
This indicator normally comes on for approx 1.8 seconds
when the ignition switch is turned "ON" ( ) & then keeps
blinking until the vehicle attains speed of 5 km/h. If there
is a problem with the anti-lock brake system, ABS
indicator turns on (page 32).
17
2
3
4
5
6
7
15
14
16
13
Function
8
9
Serv
241.6 km
F F F
to go
11
10
12
