Overloading or improper loading can cause
•
a crash and you can be seriously injured.
Follow all load limits and other loading
•
guidelines in this manual.
Load limits and weight distribution
This vehicle is designed to carry the rider (1)
and one pillion (2). The overall weight should
be distributed in four points (A, B, C, and D)
and should never exceed the maximum load
capacity of 130 kg. This will assure higher
stability, better drivability and more comfort.
(1)+(2)=130 kg
2 1
C
A
D
(A) Rider seat
(C) Pillion seat
Damages caused by excessive load will not be
covered under
Hero MotoCorp
policy. If you are not sure about how to
calculate the load weight that can be
accommodated to your vehicle without
causing overload and structural damages, see
your Authorised
Hero MotoCorp
WARNING
{where,1=A+B & 2=C+D}
B
(B) Rider footrest
(D) Pillion footrest
warranty
workshop.
Loading guidelines
Your vehicle is primarily intended for
transporting you and a pillion. If you wish to
carry cargo, check with your Authorised
workshop for advice and be sure to
MotoCorp
read the information regarding accessories on
(page 13).
Improperly loading your vehicle can affect its
stability and handling. Even if your vehicle is
properly loaded, you should ride at reduced
speeds whenever carrying cargo.
Follow these guidelines whenever you carry a
pillion or cargo:
Keep cargo and accessory weight low and
•
close to the center of the vehicle. Load
weight equally on both sides to minimize
imbalance. As weight is located further from
the vehicle's center of gravity, handling is
proportionally affected.
Adjust tyre pressure (page 64) to suit load
•
weight and riding conditions.
Vehicle handling and stability can be
•
adversely affected by loose cargo. Recheck
cargo security and accessory mounts
frequently.
Do not attach large or heavy items to the
•
handlebars, front fork or fender. Unstable
handling or slow steering response may
resul
t.
