HERO XPULSE 200 PROGRAMMED FI Manual page 65

Fluid level - Ensure that the brake fluid level
does not fall below "LWR" (lower) mark (2)
on master cylinder, when checked with the
master cylinder parallel to the ground. The
level decreases gradually due to piston
movement to compensate pad wear. If the
level decreases abruptly, check for the
leakages in the brake system and consult your
Authorised
Hero MotoCorp
4
(3) Front brake caliper
(5) Disc
Clean the dirt and mud accumulation
•
between the front brake caliper (3), brake
pads (4) and the disc (5) by using a water jet.
Always contact
•
workshop for refilling of master
MotoCorp
cylinder/reservoir when necessary. Do not
mix DoT 3 and DoT 4 brake fluid.
Always use recommended tyres (page 64)
•
for better braking performance.
workshop.
3
5
(4) Brake pad
NOTE
your Authorised
(b) Rear brake
Refer to the safety precautions on (page 44).
Reservoir (1)
Location : Near pillion footrest.
Brake fluid recommended:
DoT-4/DoT-3.
(1) Reservoir
Fluid level - Ensure that the brake fluid level
does not fall below "LOWER" mark (2) on the
reservoir parallel to the ground. The level
decreases gradually due to piston movement
to compensate pad wear. If the level decreases
abruptly, check for the leakages in the brake
system and consult your Authorised
workshop.
Hero
MotoCorp
61
2 1
(2) "LOWER" mark
