FRONT VIEW
5
4
3
2
1
(1) Leg guard
(2) Headlamp (High beam)
(3) Right position lamp
(4) Front right turn signal lamp
(5) Right hand guard
(6) Wind screen
*Accessories and features shown may not be part of standard fitment.
VEHICLE VIEWS
2
(7) Left hand guard
(8) Headlamp (Low beam)
(9) Front left turn signal lamp
(10) Left position lamp
(11) Engine oil cooler
6
7
8
9
10
11
