Adjust the Installed Gap

After checking for Free Play Gain, you may need to adjust
the installed gap. If Free Play Gain is optimal, continue to
"SHIFTING AND OPERATION"
If Free Play Gain is not optimal, the installed gap needs to
be adjusted.
The installed gap should be fine-tuned in small increments
and then recheck Free Play Gain. Refer to the table below to
set the proper installed gap based on your Free Play Gain.
Symptom
· Too much Free
Play Gain: Clutch
lever moves in too
far
· Clutch has
excessive drag or
stalls
· It is difficult to fully
override the clutch
with the lever
Reason
Installed gap
is too small
Doc ID: 191-6216200A
Doc Rev: 081720
Solution
Tighten the cable;
increase the length
of the in-line cable
adjuster housing
and/or the lever
perch adjuster
(extend the
adjusters) until the
correct amount of
Free Play Gain is
achieved.
Recheck Free Play
Gain.
Pg. 25
