Rekluse RadiusX FTR 1200 Installation & User Manual page 20

Lever with "slack" th "slack"
removed
1/8"-1/4" (3 mm-6 mm) lever movement
· If there is too much Free Play Gain, the installed gap
is too small.
o The vehicle may drag and stall because it has
difficulty disengaging the clutch. It may also be
difficult to shift.
o Too much Free Play Gain will not hurt the clutch, but
it will negatively affect clutch performance. dd
· With too little or no Free Play Gain, the installed gap is
too large.
Pg. 20
Free Play Gain e Pl
Doc ID: 191-6216200A
Doc Rev: 081720
Lever position
around 2,000 RPM
