4. Install a TorqDrive friction disk followed by a 0.40" drive
plate.
5. Continue to alternate the remaining 4 TorqDrive friction
disks with 4 of the 0.040" steel drive plates.
6. On top of the last drive plate, install the EXP assembly.
7. Install the last 0.040" drive plate
Pg. 12
TorqDrive Frictions
0.040" Drive Plates
Doc ID: 191-6216200A
Doc Rev: 081720
EXP
