4. Remove the front exhaust heat sheild.
5. Unplug the oxygen sensor connector from the front
header pipe.
6. Remove the head pipe fasteners securing the head pipe
to the cylinder head.
7. Loosen the two exhaust clamps securing the front and
rear header pipes.
8. Remove the front head pipe assembly.
Doc ID: 191-6216200A
Doc Rev: 081720
Pg. 7
