ADJUST THE INSTALLED GAP

After checking for Free Play Gain, you may need to adjust the
installed gap. If Free Play Gain is optimal, continue to "BREAK IN
THE NEW CLUTCH." If Free Play Gain is not optimal, the
installed gap needs to be adjusted.
The installed gap should be fine-tuned in small increments and
then recheck Free Play Gain. Refer to the table below to set the
proper installed gap based on your Free Play Gain.
Symptom
· Too much Free Play
Gain: Clutch lever
moves in too far
· Clutch has
excessive drag or
stalls
· It is difficult to fully
override the clutch
with the lever
· Too little Free Play
Gain: Clutch lever
only moves slightly
or does not move at
all
· Clutch slips
· Bike seems to lose
power
Reason
Installed gap is
too small
Installed gap is
too large
Doc ID: 191-6203A
Doc Rev: 100219
Solution
Turn the adjuster
clockwise to increase
the Installed Gap.
Recheck Free Play
Gain.
Turn the adjuster
counterclockwise to
reduce the Installed
Gap. It may be helpful
to re-find the starting
point.
Recheck Free Play
Gain.
