Craft Port - DPS Telecom NetGuardian V16 G2 User Manual

20
LED
Alarm
Error
Primary
Power
Craft
Status
6.1

Craft Port

Use the front panel craft port to connect the NetGuardian to a PC for onsite unit configuration. To use
the craft port, connect the included USB download cable from your PC to the craft port.
Status
Flashing Red New alarm
Solid Red Standing alarm acknowledged
Flashing Red System error
Flashing Green Data transmitted on PRI Serial
Flashing Red Data recieved on PRI Serial
Solid Green Power supply OK
Off No voltage or power leads reversed
Flashing Green Transmitting data over craft port
Flashing Red Receiving data over craft port
Flashing Green Application is running
Flashing Red Boot Loader is running
Front Panel LED Descriptions
Description
