Virtual Controls (PGE Only)

The NetGuardian's Virtual Control Relays can be configured in the Provisioning>Virtual Controls menu.
Virtual Controls allow you to manage a group of controls based on a set of instructions.
Basic Virtual Controls Configuration
ID: ID number for the Virtual Control
Description: User-definable description for the NetGuardian's Virtual Relay
Enabled: Allows user to Enable/Disable certain Virtual Controls
Control Group:Group of Controls that will be included in Virtual Control
Script: Instructions that the Control Group will follow when Virtual Control is triggered
Validate: Allows User to check the entered Control Group and Script to ensure that the syntax is
correct
Control Group:
· All Control Index's need to be followed by a comma (","), except for the last control
-Example:
Control: 1,12,4,18
-Order of execution:
Control 1 > Control 12 > Control 4 > Control 18
Script:
· Available Functions:
OPR (Operate Controls)
RLS (Release Controls)
DLY(x) (Delay time for x milliseconds)
· All Script Functions are case sensitive and need to entered in UPPERCASE format.
-Example:
Control Group: 1,12,4,18
Script: OPR,DLY(5000),RLS,DLY(1000)
Fig. 11.18 Provisioning > Virtual controls
