ID
Enab
Description
Notification Devices
Record Freq
Deadband
On Set
On Clear
Qual Time
(Qualification Time)
Qual. Type
(Qualification Type)
Units
Low Ref
High Ref
Thresholds
Analog Gauge Type
Basic Analog Configuration
Analog ID number.
Check this box to enable the analog.
User-definable description for the analog channel.
Check which notification device(s), 1 through 8, you want to send alarm
notifications for that alarm point.
Advanced Analog Configuration (Details>>)
The amount of time, in minutes (min) or seconds (s), between each log of
each analog value to history.
The amount (in volts) that the channel needs to go above or below a
threshold in order to cause an alarm.
User-definable description (condition) that will appear for the temperature
alarm on Set. Example: "Alarm".
User-definable description (condition) that will appear for the temperature
alarm Clear. Example: "Alarm Cleared".
The length of time that must pass, without interruption, in order for the
condition to be considered an Alarm or a Clear.
Allows you to choose whether you want to apply the Qualification Time to the
alarm Set, Clear, or Both.
User-definable display units or optional choice between Fahrenheit and
Celsius temperatures. The most common are:
User can click on the units box to cycle between availble unit types
User-definable lower reference/scaling level. This scales the information
collected by the sensor (in mA or VDC) to a meaningful unit for the user. For
example, for a temperature sensor, the lower input collected by the sensor
may be 4mA (for a 4-20mA sensor), which would correspond to a specific
temperature you define in this field.
User-definable upper reference/scaling level. This scales the information
collected by the sensor (in mA or VDC) to a meaningful unit for the user. For
example, for a temperature sensor, the upper input collected by the sensor
may be 20mA (for a 4-20mA sensor), which would correspond to a specific
temperature you define in this field.
These settings are set to indicate the severity of the alarm depending on
which threshold values have been passed. Enter values for Major Under
(MjU), Minor Under (MnU), Minor Over (MnO), and Major Over (MjO).
Select the color-coded gauge that best represents your data. Selecting
None will disable the analog gauge and only a numerical representation of
the value will be displayed under Monitor > Analogs.
VDC = Voltage
%H = Humidity
F = Fahrenheit
C = Celsius
