  • Page 1 HST-3000 OLP-3057 FTTx/PON Selective Optical Power Meter User’s Guide...
  • Page 3 HST-3000 OLP-3057 FTTx/PON Selective Optical Power Meter User’s Guide...
  • Page 4 Copyright © Copyright 2009 JDS Uniphase Corporation. All rights reserved. JDSU, Communications Test and Measurement Solutions, and the JDSU logo are trademarks of JDS Uniphase Corporation (“JDS Uniphase”).
  • Page 5 Industry Canada This Class B digital apparatus complies with Canadian Requirements ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 6 JDSU can be found in the Environmental section of JDSU’s web site at www.jdsu.com. If you have questions concerning disposal of your equipment or batteries, contact JDSU’s WEEE Program Management team at WEEE.EMEA@jdsu.com. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 7 Test ports ........4 Instrument settings and user preferences ... 5 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 8 Editing the reference level ..... . 25 Measuring optical levels......26 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 9 General specifications ......34 Ordering information......34 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 10 Contents viii HST-3000 OLP-3057 Optical Power Meter User’s Guide...

  • Page 11: Table Of Contents

    “Application-oriented user guide” on page xi – “HST-3000 base unit user’s guide” on page xi – “Safety and compliance information” on page xii – “Conventions” on page xiii – “Technical assistance” on page xv HST-3000 OLP-3057 Optical Power Meter User’s Guide...

  • Page 12: Purpose And Scope

    HST-3000’s OLP-3057 SIM. Assumptions This guide is intended for novice, intermediate, and experi- enced users who want to use the HST-3000 OLP-3057 SIM efficiently and effectively. We assume that you are familiar with and basic fiber optic and telecommunications safety, concepts, and terminology.

  • Page 13: Application-Oriented User Guide

    The HST-3000 OLP-3057 Optical Power Meter User’s Guide is an application-oriented user’s guide containing infor- mation about using the HST-3000 OLP-3057 SIM to perform test operations on optical fibers. This guide includes an over- view of testing features, instructions for using the HST-3000 in monitor and terminate test operations, and test result descriptions.

  • Page 14: Safety And Compliance Information

    – Please heed the normal precautions for working with lasers and consider local regulations. Additional afety and compliance information are contained in a separate guide and are provided in printed format with the product. HST-3000 OLP-3057 Optical Power Meter User’s Guide...

  • Page 15: Conventions

    A plus sign + indicates simul- Press Ctrl+s taneous keystrokes. A comma indicates consecu- Press Alt+f,s tive key strokes. A slanted bracket indicates On the menu bar, click choosing a submenu from Start > Program Files. menu. xiii HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 16 WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. HST-3000 OLP-3057 Optical Power Meter User’s Guide...

  • Page 17: Technical Assistance

    Technical Assistance number, e-mail the North American Technical Assistance Center, tac@jdsu.com, or submit your question using our online Technical Assistance Request form at www.jdsu.com. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 18 About This Guide Technical assistance HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 19 OLP-3057. Topics discussed in this chapter include the following: – “About the OLP-3057 Power Meter” on page 2 – “Exploring the OLP-3057” on page 4 – “Instrument settings and user preferences” on page 5 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 20 For detailed ordering information see “Ordering information” on page 34. However the OLP- 3057 connector must mach the type of the cable connector: – PC (BN 2291/02, BN 2291/03) – APC (BN 2291/22, BN 2291/23) HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 21 The “Auto λ“ function allows automatic wave- length detection. A wavelength encoding light source is needed to support this feature e.g. the JDSU OLS-55 Optical Light Sources. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 22 The Batt LED indicates the battery status. For more informa- tion, see the HST-3000 Base Unit User’s Guide. Test ports The OLP-3057 has three optical test ports, as shown in Figure Test port cover Test ports Figure 1 OLP-3057 test ports HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 23 “Connections”. Instrument settings and user preferences For information about changing instrument and preference settings, such as date and time format, port settings, sound, and screen settings, see the HST-3000 Base Unit User’s Guide. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 24 Chapter 1 Getting Started Instrument settings and user preferences HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 25 Topics discussed in this chapter include the following: – “Fitting adapters to the plug connectors” on page 8 – “Cleaning the test ports” on page 9 – “Connecting to the line” on page 10 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 26 However, the OLP-3057 connector type must match the type of the cable connector. To fit adapters to the plug connectors 1 Open the cover. 2 Place the test adapter vertically on the optical connector. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 27 This prevents them from getting dirty. To clean the test ports 1 If the HST is on, press the green power button to power down the unit. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 28 Using the FTTx mode, you can measure signal power by signal power inserting the OLP-3057 into the signal path as shown in Figure Optical Line Terminal Optical Network downstream Termination upstream (1490/1550 nm) (1330 nm) Figure 2 Connections for measuring signal power HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 29 Measuring Using the Broadband mode, you can measure broadband broadband signals, using the connector on the side of the SIM as shown Figure signals Broadband port Figure 3 Connection for measuring broadband signals HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 30 Chapter 2 Connections Connecting to the line HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 31 This chapter provides task-based instructions for running optical tests. Topics discussed in this chapter include the following: – “Accessing the OLP-3057 feature” on page 14 – “FTTx testing” on page 14 – “Broadband testing” on page 20 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 32 – “Selecting FTTx mode” on page 15 – “Measuring optical levels” on page 15 – “Storing and editing reference levels” on page 16 – “Loading, editing, and storing threshold masks” on page 17 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 33 2 Select a measurement mode by doing the following. a From the FTTx Summary screen, press the Action soft key. b Select a measurement mode. Measurement Description mode ABS (dBm) Absolute measurement mode, with results displayed in dBm. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 34 1 Run a test in absolute measurement mode. 2 Press the Reference soft key. 3 Select Abs-> Ref. The absolute power level is stored as new reference value and the display switches to relative measurement mode. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 35 6 Edit the reference value for 1550 nm and then press OK. The measured power level is calculated and displayed. Loading, Before doing a Pass/Fail test, a threshold mask must be spec- ified. editing, and storing threshold masks HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 36 A default threshold mask with standard values is pre-defined at the factory. Loading a stored If you have stored specific threshold mask values, do the threshold mask following to select the threshold mask. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 37 6 Proceed to next wavelength by pressing the OK key again. 7 To store these settings, press the File soft key then select Save file. 8 Enter the file name and then press OK. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 38 The Broadband Summary menu appears. Selecting a The wavelength to be measured can be selected from the Set wavelength Lambda list (under the Display soft key). In this list, up to eight wavelengths can be listed. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 39 3 Press the Show soft key to toggle the check mark. The check mark indicates whether the wavelength is shown (checkmark) or hidden (blank) in the Set Lambda list. 4 Repeat steps 2 and 3 to select up to 8 wavelengths. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 40 “AUTO λ”], like the JDSU OLS-55/-56) by a certain frequency, which can be detected by the OLP-3057. It may not be possible to detect wavelengths reliably if the following issues occur. – if the receive level is too low HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 41 The wavelength table menu appears. 2 Press the AutoL soft key to turn ON (enable) or turn OFF (disable) Auto lambda recognition. The checkmark next to Auto lambda recognition will appear if Auto lambda is enabled. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 42 0.00 dBm will be used as reference value. Relative measurement mode can also be acti- vated by storing the absolute power level as reference value (see “Storing an absolute value as a reference” on page 16). HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 43 5 If there are more wavelengths, pressing OK will move to the next wavelength. Repeat step The new reference values appear on the screen, and the measured power level is calculated and displayed. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 44 To measure optical levels – Connect to the line as described in “Connecting to the line” on page Measurement results appear on the screen. For more infor- mation on the results, see Chapter 4 “Test Results”. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 45 “About test results” on page 28 – “Summary” on page 28 – “Graphs” on page 29 – “Statistics” on page 29 – “Identity” on page 30 – “Saving and printing results” on page 30 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 46 Shows the reference level for relative mea- (“Ref.” in FTTx surement mode. In absolute measurement mode) mode, “----” appears. Thr. Mask Shows the name of the selected threshold mask. NOTE: This result only appears in FTTx mode. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 47 Pass/Fail Report the percentage of the wavelength results that meets each criteria of the threshold mask. NOTE: This result only appears in FTTx mode. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 48 Chapter 4 Test Results Identity Identity This category reports the identity of the module. Saving and printing results For information about saving and printing test results, see the HST-3000 Base Unit User’s Guide. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 49 Specifications Appendix A This appendix contains specifications for the OLP-3057. Topics discussed in this appendix include the following: – “OLP-3057 specifications” on page 32 – “Ordering information” on page 34 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 50 Automatic wavelength detection (Broadband) In combination with OLS-5, OLS-6, OLS-55, or OLS-56 In power level rate: 800 to 1299nm and 1551 to 1650 nm -45 to +5 dBm 1300 to 1550 nm -50 to +5 dBm HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 51 4. +15 to -30 dBm at 1490/1550 nm, +10 to -20 dBm at 1310 nm upstream. 5. For power >-40 dBm. 6. At -20 dBm (CW), 9 to 50μm fiber. 7. 1310 nm ±1 nm. 23°C ±3K, 45 to 75% relative humidity. HST-3000 OLP-3057 Optical Power Meter User’s Guide...
  • Page 52 BN 2291/03 HST-3000 Broadband, APC BN 2291/23 Table 12 provides the ordering information for the HST-3000 accessories. Table 12 OLP-3057 accessories ordering information Part Ordering number FC adapters BN 2150/00/51 SC adapters BN 2150/00.58 HST-3000 OLP-3057 Optical Power Meter User’s Guide...
