Multiple Cylinder Installation Dimensions, Inches - Kidde Fire Systems ECS Manual

Design and Installation
Figure 4-12. Multiple Cylinder Installation, Vertical Mounting (see Table 4-14 and Table 4-15 for
Cylinder Part Number
October 2014
A
(TYP)
CYLINDER
(TYP)
C
(BOLT SIZE)
FLOOR
D
LEVEL
Table 4-14. Multiple Cylinder Installation Dimensions, Inches
90-10001X-001
90-10002X-001
90-10004X-001
90-10007X-001
90-100125-001
90-10020X-001
90-10020X-101
90-10035X-001
90-10060X-001
90-10060X-100
90-10090X-001
ANCHOR AND STUD (TYP)
B B B
dimensions)
Dimensions
A B
8.52 11.00
8.52 11.00
10.69 13.00
10.69 13.00
14.56 18.00
15.44 18.00
14.56 18.00
17.88 21.00
24.12 27.00
25.75 27.00
25.75 30.00
4-28
WALL
FRAMING
CYLINDER
SUPPORT
CYLINDER
STRAP
VERSABAR
C D
3/8 7.38
3/8 12.50
3/8 10.63
3/8 20.00
9/16 20.88
9/16 29.63
9/16 29.63
9/16 37.13
9/16 34.00
9/16 38.50
9/16 48.50
06-236115-001
