Table 4-15. Multiple Cylinder Installation Dimensions, Millimeters

4-3.10.3 Main and Reserve System

Install main and reserve systems as instructed in the previous paragraphs.
4-3.11 Installation of Electric Control Heads
Before installing a control head on an HFC-227ea cylinder valve, ensure the
control head is in the SET position (that is, the actuating pin is in the fully
retracted or SET position). Failure to position the control head in the SET
position will result in accidental HFC-227ea cylinder discharge when the control
head is installed on cylinder valve. Personal injury and/or property damage
could occur.
WARNING
Electric Control Head, P/N 82-486500-010 is designed for Kidde 1½ in, 2 in and
2½ in HFC-227ea cylinder valves only. Installing this control head on any other
device (for example, pressure operated control head) will cause the device to
malfunction when the control head is actuated.
1. Remove the protection cap from the HFC-227ea cylinder actuation port. Ensure the control
head is in SET position (that is, the actuating pin is in the fully retracted or SET position).
2. Install the electric control head on the cylinder actuation port. Tighten the swivel nut.
3. Make all electrical connections.
Note: P/N 82-486500-010 is a polarized control head. Improper wiring will cause the device
to malfunction.
The stackable control head (P/N 82-486500-010) cannot be used with the 3-
inch valve cylinder (P/Ns 90-100600-100, 90-100601-100, 90-100900-001 and
90-100901-001). The stackable control head does not have sufficient force to
CAUTION
activate the 3-inch valve (P/N 90-17000-000) and may result in system failure.
Use the electric/manual control heads (P/Ns 8901XX) with the 3-inch valve.
06-236115-001
Cylinder Part
Number
A
90-10001X-001 216
90-10002X-001 216
90-10004X-001 272
90-10007X-001 272
90-100125-001 370
90-10020X-001 392
90-10020X-101 370
90-10035X-001 454
90-10060X-001 613
90-10060X-100 654
90-10090X-001 704
4-29
Dimensions
B C D
279 10 187
279 10 318
330 10 270
330 10 508
457 14 530
457 14 753
457 14 753
533 14 943
686 14 864
686 14 864
762 14 1232
Design and Installation
October 2014
