Discharge Nozzles; 7-3.1 Ul Listed 360 Degree Nozzles - Kidde Fire Systems ECS Manual

7-3

DISCHARGE NOZZLES

Only listed Kidde ECS System HFC-227ea nozzles are to be used on Kidde ECS
Systems. Failure to comply with this WARNING can result in unpredictable
WARNING
agent distribution.
7-3.1 UL Listed 360 Degree Nozzles
Note:
An additional nozzle finish has been added for a special application. This is a nickel plated nozzle
designed to the specifications of the brass version which is FM Approved. The part numbers are
exact to that below except for the sixth digit which is a "3" instead of a "0"
2
Area (in )
1/2 in NPT
0.0774 90-194023-111
0.0802 90-194023-113
0.0845 90-194023-116
0.0905 90-194023-120
0.0982 90-194023-125
0.1037 90-194023-129
0.1162 90-194023-136
0.1240 90-194023-141
0.1303 90-194023-144
0.1358 90-194023-147
0.1404 90-194023-150
0.1534 90-194023-156
0.1629 90-194023-161
0.1731 90-194023-166
0.1856 90-194023-172
0.1968 90-194023-177
0.2035 90-194023-180
0.2080 90-194023-182
0.2150 90-194023-185
0.2244
0.2353
0.2488
0.2653
0.2851
0.3007
0.3069
0.3266
0.3440
0.3559
0.3802
06-236115-001
UL Listed 360 Degree Nozzles
3/4 in NPT 1 in NPT
90-194024-147
90-194024-150
90-194024-156
90-194024-161
90-194024-166
90-194024-172
90-194024-177
90-194024-180
90-194024-182
90-194024-185
90-194024-189 90-194025-189
90-194024-194 90-194025-194
90-194024-199 90-194025-199
90-194024-206 90-194025-206
90-194024-213 90-194025-213
90-194024-219 90-194025-219
90-194024-221 90-194025-221
90-194024-228 90-194025-228
90-194024-234 90-194025-234
90-194024-238 90-194025-238
90-194025-246
1-1/4 in NPT
90-194026-246
7-7
Parts List
.
1-1/2 in NPT 2 in NPT
October 2014
