INTRODUCTION AND PARTS LIST

The table below, and on the following pages, provides a complete list of the Kidde Fire Systems
ECS Fire Suppression System with HFC-227ea Agent parts and associated system equipment.
Equipment can be ordered as complete assemblies or as individual items. In most situations,
when ordering a system, it will be easier and more cost effective to order by assembly part
numbers.
Note: Unless otherwise noted, the parts documented in this section are UL Listed and FM Ap-
proved. For non-agency approved parts, see datasheet K-90-2075.
Cylinder/Valve Assemblies
10 lb STD
20 lb STD
40 lb STD
70 lb STD
125 lb STD
125 lb W/LLI
200 lb STD Old Style Hemispherical Head before 3/98
200 lb W/LLI Old Style Hemispherical Head before 3/98
200 lb STD New Style Ellipsoidal Head after 3/98
200 lb W/LLI New Style Ellipsoidal Head after 3/98
350 lb STD
350 lb W/LLI
600 lb STD old style supplied before 9/01 (discontinued)
600 lb W/LLI old style supplied before 9/01 (discontinued)
600 lb STD new style supplied after 9/01
600 lb W/LLI new style supplied after 9/01
900 lb STD
900 lb W/LLI
(STD=Standard Cylinder Assembly, W/LLI=Cylinder with liquid level indicator)
Flexible Discharge Hoses
10-125 lb Cylinders
200-350 lb Cylinders
600 lb Cylinders (old style supplied before 9/01)
600 lb Cylinders (new style after 9/01)
900 lb Cylinders
06-236115-001
CHAPTER 7
PARTS LIST
Table 7-1. Parts List
Nomenclature Part Number
WK-283898-000
WK-283899-000
WK-283900-000
7-1
Parts List
Original P/N
90-100010-001
90-100020-001
90-100040-001
90-100070-001
90-100125-001
90-100121-001
90-100200-001
90-100201-001
90-100200-101
90-100201-101
90-100350-001
90-100351-001
90-100600-001
90-100601-001
90-100600-100
90-100601-100
90-100900-001
90-100901-001
283898
283899
283900
06-118225-001
06-118225-001
