Figure 3. Order of Installation for Electric Control Head, P/N WK-890181-000
PLUS OR HOT CONNECTION
Figure 4. Electrical Connections for Control Head, P/Ns WK-890181-000
06-236115-003
0.750 NPT TO FLEXIBLE
CONDUIT ADAPTER
(TERMINAL 3)
TERMINAL STRAP
MICROSWITCH
MICROSWITCH
LEVER
INDICATOR AND
RESET STEM
FLEXIBLE CONDUIT
OPTIONAL CONNECTION
FOR MICROSWITCH
(TERMINAL 2)
MINUS, NEUTRAL
OR GROUND CONNECTION
(TERMINAL 1)
3
2
SWIVEL
NUT
CAM
5
July 2016
