4-3.10.2 Multiple Cylinder System

Cylinders must be located and mounted where they will not be accidently
damaged or moved. If necessary, install suitable protection to prevent the
WARNING
cylinder from damage or movement.
1. Position the cylinders in the designated location and secure them in place with cylinder
straps and attaching hardware (see Figure 4-12 and Table 4-14 and Table 4-15). Orient the
cylinders so that the valve outlets are angled towards the El-check valves in the manifold.
The discharge hose must be connected into the system piping before attaching
it to the cylinder valve.
WARNING
2. Remove the safety cap from one cylinder outlet port and connect the flexible discharge
hose to the cylinder outlet port. Repeat for each cylinder in the system.
3. Remove the protection caps from the cylinder actuation ports.
4. Install the control heads on the cylinder valve actuation ports.
Control heads must be in the SET position (that is, the actuating pin must be in
the fully retracted or SET position) before attaching to HFC-227ea cylinders in
order to prevent accidental discharge. Personal injury and/or property damage
WARNING
could occur.
06-236115-001
Table 4-13. Strap Part Numbers for Cylinder Installation
Strap Part Number
WK-283945-000
WK-283934-000
WK-292971-000
06-235317-001
WK-281866-000
WK-294651-000
06-236125-001
Cylinder Size
10 and 20 lb
40 and 70 lb
125 and 200 lb (old style)
125 and 200 lb (new style)
350 lb
600 lb
900 lb
