Single Cylinder Installation Dimensions, English (Inches); Single Cylinder Installation Dimensions, Metric (Millimeters) - Kidde Fire Systems ECS Manual

Design and Installation
Table 4-11. Single Cylinder Installation Dimensions, English (inches)
Cylinder P/N
90-10001X-001
90-10002X-001
90-10004X-001
90-10007X-001
90-100121-001
90-100125-001
90-10020X-001
90-10020X-101
90-10035X-001
90-10060X-001
90-10060X-100
90-10090X-001
Note: The "X" within the part numbers denotes whether a Liquid Level Indicator (LLI) is ordered with the
cylinder. A one (1) is used if a LLI is needed, a five (5) is used if one is not.
Table 4-12. Single Cylinder Installation Dimensions, Metric (millimeters)
Cylinder P/N
90-10001X-001
90-10002X-001
90-10004X-001
90-10007X-001
90-100121-001
90-100125-001
90-10020X-001
90-10020X-101
90-10035X-001
90-10060X-001
90-10060X-100
90-10090X-001
Note: The "X" within the part numbers denotes whether a Liquid Level Indicator (LLI) is ordered with the
cylinder. A one (1) is used if a LLI is needed, a five (5) is used if one is not.
October 2014
A B
9.62 7.19
9.62 7.19
11.69 9.13
11.69 9.13
16.18 12.94
16.18 12.94
17.06 13.78
16.18 12.94
19.50 16.19
25.75 22.25
25.75 22.25
27.75 25.00
A B
244 183
244 183
297 232
297 232
411 329
411 329
433 350
411 329
495 411
654 565
654 565
704 635
4-26
C D
7.07 8.52
7.07 8.52
9.00 10.69
9.00 10.69
12.75 14.56
12.75 14.56
13.60 15.44
12.75 14.56
16.00 17.88
22.00 24.12
22.00 24.12
24.00 26.00
C D
180 216
180 216
229 272
229 272
324 370
324 370
345 392
324 370
406 454
559 613
559 613
610 660
E F
7.38 3/8
12.50 3/8
10.63 3/8
27.50 3/8
23.75 9/16
23.75 9/16
39.00 9/16
39.00 9/16
44.00 9/16
38.50 9/16
38.50 9/16
48.50 9/16
E F
187 M10
318 M10
270 M10
699 M10
603 M14
603 M14
991 M14
991 M14
1118 M14
978 M14
978 M14
1232 M14
