4. To o ls Set t ing [ TOOL]
As an example, in the fi gure above, it needs to move in negative directions for both X and Y directions, so both of
the adjustment values will be negative values.
7. Repeat the procedures 5 to 6 until the difference between tools disappears.
What is initial adjustment of the blade direction:
Initial adjustment of the blade direction is an operation that softly puts the blade on the media to align the blade
directions right after turning on the power source of plotter or after changing the condition settings.
