Panel Catting
* Unavailable for FC8000.
To prevent long skew, utilize partition length when cutting.
• When Panel Cutting is on, the machine will begin by dividing up partition length and continue cutting until one
of the following data breaks appears. When the fi rst partitioned area cut is fi nished, the machine will move to the
next area, and repeat this until all areas have been cut.
• Data Breaks:
(1) No data sent for a few seconds after fi nishing cutting. (Time Out)
(2) A feed-related command is set. (GP-GL - F, SO commands, HP-GL - AF, AH, PG commands)
(3) HP-GL - SP0, NR, GP-GL - J0
(4) When commands from data breaks (2) and (3) appear, that command work will begin after the partition
pastern cutting is fi nished.
• Panel cutting will continue for each piece of data when a data break is caused by a command, even if multiple
pieces of data are sent in before the cutting fi nishes (even when numerous pieces of panel cutting data are in
the plotter buffer).
• When panel cutting and auto media transfer are both turned on, the machine will ignore automatic media transfer
length settings and continue working with priority of partition length +α minutes ago (with footprints).
• When panel cutting is on, registration marks will not be seen ignored, and copy, origin point, initial feed, and
cutting area cannot be changed.
• If 1 piece of data causes the buffer to be full, partition linking will not be possible. Make sure only to send data
that is below the buffer size.
What is Pre Feed
This function prevents the loaded media from slipping by advancing the media by the specifi ed length and then
drawing back to imprint grit roller marks on the media. It also ensures stable media feed operations by acclimating
long media to the operating environment. For roll media, the amount to use for plotting must be pulled out
beforehand. You can let the plotter do this work.
AP Mode
This function is used to connect to a CAD for AP (apparel industry).
The media is fed when data is not received within the specifi ed time after fi nishing
Time Out the plotting, Select a value from 0, 1, 2, 3, 5, 10, 20, 30, 60, and 120 seconds.
When [0] is set, the media will not be fed.
Set the command to be used as the separator of data. One sheet is plotted every
Separator GP-GL
time the data is separated. Select a value from - (no separator is set), F, J0, H, and
FS.
Set the command to be used as the separator of data. One sheet is plotted every
Separator HP-GL
time the data is separated. Select a value from - (no separator is set), AF, AH, PG,
NR, SP, IP, SC, IW, PS, DF, and IN.
Specify the space for between the position where plotting data is terminated and
Space Rear
the position for cutting off the media. The possible values are from 7.0 to 30.0 mm.
