Frequency/Voltage Control - Elitegroup Computer Systems P6IWM Manual

Frequency/Voltage Control

This item enables you to set the clock speed and system bus
for your system. The clock speed and system bus are deter-
mined by the kind of processor you have installed in your
system.
CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software
Auto Detect DIMM/PCI Clk
Spread Spectrum
CPU Host/SDRAM/PCI Clock
CPU Clock Ratio Jumpless
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal
of free DIMM and PCI slots.
Spread Spectrum (Enabled)
If you enable spread spectrum, it can significantly reduce the
EMI (Electro-Magnetic Interference) generated by the system.
CPU Host/SDRAM/PCI Clock (Default)
Use the CPU Host Clock to set the frontside bus frequency for
the installed processor (usually 133 MHz, 100 MHz or 66
MHz).
CPU Clock Ratio Jumpless (By H/W)
Use the CPU Host/SDRAM/PCI Clock to set the frontside bus
frequency for the installed processor (usually 133 MHz, 100
MHz or 66 MHz). Then use CPU Clock Ratio Jumpless to set
a multiple. The multiple times the frontside bus must equal the
core speed of the installed processor e.g., 3.5 (multiple) x
100 MHz (frontside bus) = 350 MHz (installed processor
clock speed).
Frequency/Voltage Control
Enabled
Enabled
Default
By H/W
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults
