Refer to the following to install the memory modules.
1. Push the latches on each side of the DIMM slot down.
2. Align the memory module with the slot. The DIMM
slots are keyed with notches and the DIMMs are keyed
with cutouts so that they can only be installed correctly.
3. Check that the cutouts on the DIMM module edge
connector match the notches in the DIMM slot:
Latch
Notches
4. Install the DIMM module into the slot and press it firmly
down until it seats correctly. The slot latches are lev-
ered upwards and latch on to the edges of the DIMM.
5. Install any remaining DIMM modules.
Cutouts
Latch
