POWER ON Function (Hot KEY)
Enables computer power on b y keyboard, mouse, or hotkey
activity.
KB Power ON Password
Enables you to set a password to be entered when using the
keyboard to power on the computer.
Hot Key Power ON (Ctrl-F12)
Enables you to select a hot key to turn on the computer.
Onboard FDC Controller (Enabled)
This option enables the onboard floppy disk drive controller.
Onboard Serial Port 1 (3F8/IRQ4)
This option is used to assign the I/O address and interrupt re-
quest (IRQ) for the onboard serial port 1 (COM1).
Onboard Serial Port 2 (2F8/IRQ3)
This option is used to assign the I/O address and interrupt re-
quest (IRQ) for the onboard serial port 2 (COM2).
UART Mode Select (Normal)
This field is available if the Onboard Serial Port 2 field is set to
any option but Disabled. UART Mode Select enables you to
select the infrared communication protocol: Normal (default),
IrDA, or ASKIR. IrDA is an infrared communication protocol
with a maximum baud rate up to 115.2K bps. ASKIR is
Sharp's infrared communication protocol with a maximum
baud rate up to 57.6K bps.
UR2 Duplex Mode (Half)
This field is available when UART 2 Mode is set to either
ASKIR or IrDA. This item enables you to determine the infra-
red function of the onboard infrared chip. The options are Full
and Half (default).
Full-duplex means that you can transmit and send information
simultaneously. Half-duplex is the transmission of data in both
directions, but only one direction at a time.
