2. Match the pins on the underside of the CPU with the
pin holes on the Socket 370. Two adjacent corners on
the Socket are missing pin holes: two corresponding
corners on the CPU are missing pins. Lower the CPU
onto the socket accordingly.
Note: The socket is designed to ZIF (Zero Insertion Force)
specifications which means that the CPU pins
should easily drop into the socket pin holes without
any exertion or pressure on the CPU.
3. Swing the locking lever down and hook it under the
latch on the edge of the socket.
4. Apply thermal grease to the top of the CPU. See your
dealer for more information about thermal grease.
5. Lower the CPU fan/heatsink unit onto the CPU socket.
Fan power cable
6. Secure the two retention clips on either side of the
fan/heatsink unit onto the Socket 370 base.
Socket 370
