Jumper Settings
Jumper
Type
Description
JP1
3-pin
BIOS flash
protection
jumper
JP2
3-pin
Clear CMOS
jumper
JP3
3-pin
CPU core
JP4
voltage select
JP5
jumper
JP6
JP7
JP1: BIOS Flash Protect Jumper
This jumper is used to protect the BIOS from being uninten-
tionally flashed. Enable this jumper for protection and disable
this jumper when you want to flash the BIOS.
JP2: Clear CMOS Jumper
This jumper enables you to reset the BIOS. Follow these
instructions to reset the BIOS:
1. Turn the system off.
2. Short pins 2 and 3 on JP2.
3. Return the jumper to the normal setting.
4. Turn the system on. The BIOS is returned to the de-
fault settings.
P
6
P
6
Setting Jumpers
Setting (default)
1-2: Disable
1
2-3: Enable
1-2: Normal
2-3: Clear CMOS
JP3
JP4JP5 JP6 JP7
1
V
P
A
2
T
V
P
A
2
T
JP1
JP2
1
