SIR1: Serial infrared port
The mainboard supports a Serial Infrared (SIR) data port. In-
frared ports allow the wireless exchange of information
between your computer and similarly equipped devices such
as printers, laptops, Personal Digital Assistants (PDAs), and
other computers.
Pin Signal Name
1 RESERVED
3 VCC
5 IRTX
LSIR1: Serial infrared port
The mainboard supports a Serial Infrared (SIR) data port. In-
frared ports allow the wireless exchange of information
between your computer and similarly equipped devices such
as printers, laptops, Personal Digital Assistants (PDAs), and
other computers.
Pin Signal Name
1 VCC
2 EMPTY
3 IRRX
4 GROUND
5 IRTX
SJ1: Single color LED header
This header allows the user to install an LED indicator to indi-
cate when the computer is in Suspend to RAM (STR) mode or
normal mode.
Pin Signal Name
1 SUSLED-Y
2 SUSLED-Y
3 PWLED+
Pin Signal Name
2 EMPTY
4 GROUND
6 IRRX
29
