LSJ1: Single color LED header
This header allows the user to install an LED indicator to indi-
cate when the computer is in Suspend to RAM (STR) mode or
normal mode.
Pin Signal Name
1 5 VSB
2 SUSLED-G
USB2: Front panel USB header
The mainboard has two USB ports installed on the rear edge
I/O port array. Additionally, some computer cases have USB
ports at the front of the case. If you have this kind of case, use
auxiliary USB connectors USB2 to connect the front-mounted
ports to the mainboard.
Pin Signal Name
1 VCC
3 DATA0-
5 DATA0+
7 GROUND
9 KEY
LUSB1: Front panel USB header
The mainboard has two USB ports installed on the rear edge
I/O port array. Additionally, some computer cases have USB
ports at the front of the case. If you have this kind of case, use
auxiliary USB connectors USB2 to connect the front-mounted
ports to the mainboard.
Pin Signal Name
1 VCC
3 USB0-
5 USB0+
7 GROUND
9 GROUND
Pin Signal Name
2 VCC
4 DATA1-
6 DATA1+
8 GROUND
10 OC
Pin Signal Name
2 GROUND
4 KEY
6 USB1+
8 USB1-
10 VCC
