SMI1: External system management interrupt
SMI1 is for use with system management interrupt (SMI)
hardware interrupt power management.
Pin Signal Name
1 EXTSMI-
2 GND
WOL1/WOM: Wake On LAN/Wake On Modem
If you have installed a LAN card, use the cable provided with
the card to plug into the mainboard WOL1 connector. This en-
ables the Wake On LAN (WOL) feature. When your system is
in a power-saving mode, any LAN signal automatically r e-
sumes the system. You must enable this item using the Power
Management page of the Setup Utility.
Pin Signal Name
1 5VSB
2 GROUND
3 WAKE_UP
If you have installed a modem, use the cable provided with
the modem to plug into the mainboard WOM1 connector. This
enables the Wake On Modem (WOM) feature.
When your system is in a power-saving mode, any modem
signal automatically resumes the system. You must enable
this item using the Power Management page of the Setup Util-
ity. See Chapter 3 for more information.
31
