External Connector Color Coding
Many connectors now use standard colors as shown in the
table below.
Connector
Analog VGA
Audio line-in
Audio line-out
Digital monitor/flat panel
IEEE 1394
Microphone
MIDI/game
Parallel
PS/2-compatible keyboard
PS/2-compatible mouse
Serial
Speaker out/subwoofer
Right-to-left speaker
USB
Video out
SCSI, network, telephone,
modem
This concludes Chapter 2. The next chapter covers the BIOS.
