Connecting Optional Devices

Refer to the following for information on connecting the main-
board's optional devices:
COM2
1
MODIN
LAUDIO1
1
1
LAUDIO1
AUDIO1
1
COM2: Second COM port
The mainboard supports a second serial (COM) port. Connect
a serial port extension bracket to this header to add a second
serial port to your system:
Pin Signal Name
1 DCD
3 SOUT
5 GROUND
7 RTS
9 RI
B T 1
1
CHS1
PCI1
A U D I O 1
1
PCI2
CASFAN1
PCI3
ISA1
SIR1
1
LSIR1
Pin Signal Name
2 SIN
4 DTR
6 DSR
8 CTS
10 KEY PIN
27
DIMM1 DIMM2
SMI1
IDE2 IDE1
FDD1
WOM1 WOL1
USB2 LUSB1
JP1
1
S M I 1
1 1
WOM1 W O L 1
LSJ1
1 1
1
1 1
1 1
LSJ1
1
SJ1
1
